PLA+Basic

Key Features

1.Enhanced Impact Resistance
2.Exceptional Layer Adhesion
3.Minimal Stringing & Oozing
4.Extended Service Life
5.Easy to Print

Dimensions：1.75mm/2.85mm

Weight of each roll：1kg/2.5kg

Color Options

Violet

Orange

Red

Yellow

Cyan

Magenta

Black

White

Dark Coffee

Blue

Gray

Dark Green

Metallic Silver

Pink

Skin Color

Sky Blue

Peach Pink

Green

Army Green

Brown

Light Brown

Dark Gray

Marble PLA

Chocolate

Orchid Purple

Apple Green

Pine Green

Aliz PLA+ Basic is a Modified formulation of the widely used polylactic acid (PLA) filament, specially engineered to overcome some of the common limitations of traditional PLA. Designed for both hobbyists and professionals, this upgraded material retains the ease-of-use and eco-friendly characteristics of traditional PLA while significantly improving toughness, durability, and printability. With enhanced impact resistance, superior layer adhesion, reduced stringing, and an extended service life, Aliz PLA+ Basic offers a more robust solution for a wider range of 3D Printing applications.

With Aliz PLA+ Basic, you get the best of both worlds — the ease of use and sustainability of PLA combined with the strength and longevity needed for real-world applications.

Key Features

Enhanced Impact Resistance

Enhanced Impact Resistance: Unlike traditional PLA which is prone to be brittle, Aliz PLA+ Basic is formulated to absorb more energy before fracturing, making it highly suitable for printed parts that require toughness.
Exceptional Layer Adhesion

Exceptional Layer Adhesion: Ensures strong interlayer bonding, resulting in higher mechanical strength and better structural integrity of printed parts.
Minimal Stringing & Oozing

Minimal Stringing & Oozing: Optimized for clean printing with minimal stringing, ensuring smoother surface finishes and less post-processing work.
Extended Service Life

Extended Service Life: The natural biodegradation cycle of Aliz PLA+ Basic is delayed, allowing for longer-lasting parts without compromising its environmentally friendly property.
Easy to Print

Easy to Print: Maintains the user-friendly properties of standard PLA — no heated bed required, low warping, and excellent dimensional accuracy.

PLA+ Basic VS Traditional PLA

PLA+ Basic and PLA share the same environmentally friendly formulation, but PLA+ Basic has optimized its layer adhesion and integrated strength, as well as more stain finishing.

Functional Prototyping

Functional Prototyping: Ideal for creating durable prototypes that can withstand handling and testing to some extent.

Educational Use

Educational Use: Great for schools and makerspaces due to its ease of use and improved durability.

Display Models & Artwork

Display Models & Artwork: Offers fine detail resolution and smooth surface finish, perfect for visual models and artistic creations.

Applications of PLA+ Basic

4

Learn More
3
2
1

____________________________

PLA+ Basic is an excellent choice for those who need the ease of printing that PLA offers but with the added benefit of improved impact resistance. Whether you're a maker looking to create more functional parts or a professional prototyping tougher components, PLA+ Basic opens up a range of new possibilities without sacrificing the print quality and user-friendliness that standard PLA is known for.

Mechanical Properties

Property	Testing Method	Testing Condition	Injection Molding Typical Value	3D Printing X-Y Axis Typical Value	3D Printing Z Axis Typical Value	Unit
Tensile Strength	ISO 527	50mm/min	63.33	34.74±4	30.34±4	MPa
Elongation at Break	ISO 527	50mm/min	3.31	5.18±1	1.6±0.2	%
Tensile Modulus	ISO 527	50mm/min	2408.34	2200.4±100	2057.5±100	MPa
Flexural Strength	ISO 178	2mm/min	91.04	58.36±4	44.31±4	MPa
Flexural Modulus	ISO 178	2mm/min	3646.67	2326.67±100	2057.5±100	MPa
Charpy Impact Strength	ISO 179	23℃	24.73	18±2	7.54±1	KJ/㎡
Izod Impact Strength	ISO 180	23℃	18.1	12.66±2	6.44±1	KJ/㎡

Physical Properties

Property	Testing Method	Testing Condition	Typical Value	Unit
Density	ISO 1183	Immersion	1.17	g/cm³
Melt Flow index(MFR)	ISO 1133	210℃/2.16kg	2-7	g/10 min

Moisture Absorption

Property	Testing Method	Testing Condition	Injection Molding Typical Value	3D Printing Typical Value	Unit
Moisture Absorption	ISO 62	50%RH*23℃	0.5	0.6	%

Chemical Properties

Property	Testing Result
Weak Acid Resistance	Not Resistant
Strong Acid Resistance	Not Resistant
Weak Base Resistance	Not Resistant
Strong Base Resistance	Not Resistant
Organic Solution Resistance	Not Resistant

Thermal Properties

Property	Testing Method	Testing Condition	Injection Molding Typical Value	3D Printing X-Y Axis Typical Value	3D Printing Z Axis Typical Value	Unit
Glass Transition Temperature	DSC	10℃/min	65.5			℃
Crystallization Temperature	DSC	10℃/min	107.7			℃
Melting Point	DSC	10℃/min	147.8			℃
Distortion Temperature	TGA	20℃/min	N/A			℃
Heat Distortion Temperature	ISO 75	0.45MPa	57.6	55.3	56.6	℃
Heat Distortion Temperature	ISO 75	1.8MPa	56.5	54.8	52.4	℃
Vicat Softening Temperature	ISO 306	50℃/10N	61.6	59.6	60	℃

Recommended 3D Printing Parameters
*Based on 0.4 mm nozzle. Printing conditions may vary with different nozzle diameters

Printing Temperature	210-230（℃）
Bed Temperature	50-60（℃）
Wall Layers	2 Layers
Top and Bottom Layers	4 Layers
Infill	100%
Ambient Temperature	25℃
Cooling Fan	0-10%
Printing Speed	30 — 50 （mm/s）
Nozzle Diameter	0.4 mm

3DPrinting Actual Parameters
*All specimens must be left at room temperature for 24 hours before testing. The parameters are based on the Bambulab P1S 3D printer.

Printing Temperature	220（℃）
Bed Temperature	55（℃）
Wall Layers	2 Layers
Top and Bottom Layers	4 Layers
Infill	100%
Ambient Temperature	25℃
Cooling Fan	10%
Printing Speed	50 （mm/s）
Nozzle Diameter	0.4 mm
